Bernardo Guide Rear for TB/BM 2020
Bernardo Guide Rear for TB/BM 2020 is backordered and will ship as soon as it is back in stock.
arriving within 1-2 months
Subscribe to our newsletter
Get the latest updates on all our new collections, sales, offers and product arrival dates.
-
Description
-
Product safety
-
Reviews
Description
Bernardo Backgauge for TB 2020 / BM 2020
The backgauge for TB 2020 and BM 2020 is a technical accessory designed for precision and repeatability in sheet metal processing. It allows for accurate positioning of the material before bending or cutting, ensuring consistent measurements and professional results. The robust steel structure and precise adjustment system enable quick and reliable settings, improving operational efficiency and reducing processing times. Perfectly compatible with TB 2020 and BM 2020 models, it is an indispensable choice for workshops and industrial environments requiring high-precision repetitive operations.
Main Specifications
Adjustable backgauge system
High precision and repeatability
Robust and durable structure
Simple and micrometric adjustment
Specific compatibility with TB 2020 and BM 2020
Suitable for professional use
Technical Data:
| Specification | Value |
|---|---|
| Compatibility | TB 2020 / BM 2020 |
| Type | Backgauge |
| Function | Precise sheet metal positioning |
| Structure | Steel |
| Adjustment | Manual micrometric |
| Use | Professional / Industrial |
Package Contents:
Complete backgauge system
Guides and mounting brackets
Mounting kit
Installation manual
Logistics
Original spare parts available with 3–5 business days shipping. Customer support in Italian available.
Frequently Asked Questions
The backgauge for TB 2020 / BM 2020 — for what operation is it essential?
The backgauge is an adjustable stop that is positioned at the back of the machine's bending table (TB 2020 / BM 2020) to position the sheet metal at the exact dimension before bending. Without a backgauge, the operator must measure and mark each piece individually — with the backgauge, the sheet is positioned against the stop and the bend is made, producing series of identical pieces without intermediate measurements. Typical precision is ±0.5 mm over the entire length of the guide.
How is the stop distance adjusted?
The backgauge has a graduated scale in mm and a micrometric adjustment screw. The stop is set to the desired dimension (distance from the bending edge), locked with the fixing lever, and a test piece is run to verify the actual dimension before series production. For angled bends, consider the material's springback — for 1 mm mild steel, springback is typically 2°–5°.
Spare parts available?
Original spare parts available with 3–5 business days shipping. Customer support in Italian available.
