The Güde Log Splitter GHS 370/4TE is a professional-grade log saw with a 1.5 kW motor. Krollit, official Güde distributor since 2007.
- Supply voltage: 230 V
- Frequency: 50 Hz
- Operating mode: S3
- IP protection: IP54
- Motor power (P1): 1.5 kW
- Motor speed: 2820 rpm
Who uses the Güde GHS 370/4TE Log Splitter and for what
The Güde GHS 370/4TE Log Splitter is a professional-grade log saw distributed by Krollit.
Its place in the Güde range
The Güde Log Splitter GHS 370/4TE is part of the Güde range of log saws, distributed in Italy by Krollit since 2007. The Güde range includes models of various categories and performance levels: to choose the right machine for your use case, you can consult the Güde catalog on Krollit or contact customer support for selection assistance.
Krollit Logistics and Support
Machine shipping in 5-9 working days (7 days for Southern Italy). For spare parts and accessories, shipping in 3-5 working days from Krollit warehouse. Italian-speaking customer support available for technical documentation, product sheets, and spare parts order management. Krollit has been an official distributor since 2007.
Who is the Güde GHS 370/4TE Log Splitter for
The Güde GHS 370/4TE log splitter is recommended for the following professional profiles:
-
Farms and hobbyist sawmills: sectioning logs and firewood with a tilting pendulum system.
-
Wood producers and green space maintainers: quick cuts on round logs up to the diameter indicated in the technical data sheet.
Not suitable for: precision cuts on boards or panels (tilting saw designed for round logs: for panels, use table saws).
Spindle, tools and speed
| Motor speed |
2820 rpm |
| Feed speed |
0.032 m/s |
| Return speed |
0.055 m/s |
Motor and power supply
| Supply voltage |
230 V |
| Frequency |
50 Hz |
| Motor power (P1) |
1.5 kW |
| Hydraulic pressure |
160 bar |
Other specifications
| Operating mode |
S3 |
| IP protection |
IP54 |
| Hydraulic oil |
HLP46 |
| Hydraulic oil quantity |
2.5 L |
| Splitting force |
4 t |
| Log diameter |
max 250 mm |
| Noise level LWA |
86 dB |
| Insulation class |
F |
| Piston stroke |
300 mm |
| Log length |
max 370 mm |
| Dimensions (L × W × H) |
1172 × 527 × 640 mm |
Frequently Asked Questions
What log diameter can the Güde GHS 370/4TE Log Splitter cut?
See "Maximum log diameter" in the technical table: typically 170-260 mm.
For larger diameter logs, consider models with a larger saw blade or band saws for logs.
Supported blade diameter?
See "Blade diameter" in the table: typically Ø 700 mm with HM teeth.
HM blades offer superior durability compared to standard blades and are suitable for continuous production.
Does it run on an electric motor or PTO?
"ZR" models have PTO for tractors; others have a 400V three-phase electric motor.
PTO models are suitable for field use without an electrical power supply.
Safety system?
Tilting saws have automatic blade protection and spring return to the rest position.
Check the technical data sheet for specific safety systems and compliance with European regulations.
Spare parts and assistance available?
Yes, original Güde/Bernardo spare parts available. Italian-speaking customer support available.
Krollit has been an official Güde distributor since 2007.
