Guida Krollit alla scelta dell'aspiratore per macchina utensile, con impianto Bernardo DC 700 a quattro sacche

Which dust extractor do you need for your lathe, mitre saw or planer?

Written by: Sandra Gaspar

|

Published on

|

Time to read 8 min

The right question is not how many m³/h the extractor delivers, but how many inlets it has and their diameter. A Bernardo DC 180 rated at 850 m³/h has one Ø 100 mm inlet and serves one machine. A DC 550 CF rated at 4,400 m³/h has four and serves three simultaneously. The number of inlets determines how many machines you can connect; the airflow determines whether it can actually handle them. As an authorised distributor since 2007, we provide the table below with the rated specifications of our range.


How much extraction each type of machine needs

Not all machines produce the same volume of chips, and this changes the airflow required.

A mitre saw cuts intermittently and produces coarse chips: extraction works in bursts. One Ø 100 mm inlet with 850 m³/h is enough.

A wood lathe generates chips continuously, but concentrated at one point. Suction pressure matters more than airflow, because the chips need to be picked up at close range: prioritise 1,020 Pa with 850 m³/h rather than the other way round.

A planer thicknesser is the most demanding machine in a woodworking shop. A Bernardo PT 305 D removes up to 160 mm of thickness across a width of 305 mm: it generates the highest volume of chips per minute in the workshop. Below 1,500 m³/h, material remains in the rollers.

A sander produces a small volume of material but fine dust, which is the health concern. This calls for a cartridge filter, rather than a fabric bag.

A CNC machining centre works continuously without stopping: extraction must last eight hours without clogging the filter. This is where a cyclone system pays off.

The table: airflow, inlets and number of machines

These are the rated specifications of the models we supply, with prices including VAT.

Model Airflow Suction pressure Inlets Power Price
Bernardo BDC 1200 portable 183 m³/h 2,500 Pa 1 × Ø 100 1.2 kW · 230 V €201.31
Bernardo DC 160 850 m³/h 700 Pa 1 × Ø 100 0.55 kW · 230 V €234.25
Bernardo DC 180 850 m³/h 700 Pa 1 × Ø 100 0.55 kW · 230 V €241.57
Bernardo RV 203 CF 850 m³/h 1,020 Pa 1 × Ø 100 0.75 kW · 230 V €359.91
Bernardo DC 200 E 1,150 m³/h 700 Pa 1 × Ø 100 0.55 kW · 230 V €289.15
Bernardo DC 250 CF 1,500 m³/h 1,020 Pa 1 × Ø 100 0.75 kW · 230 V €590.50
Bernardo FT 200 N 2,000 m³/h 1,800 Pa 2 × Ø 100 1.5 kW · 400 V €512.41
Bernardo DC 300 2,520 m³/h 1,800 Pa 1×130 / 2×100 1.5 kW · 230 V €480.69
Bernardo DC 450 CF 2,800 m³/h 1,800 Pa 1×130 / 2×100 1.5 kW €849.14
Bernardo FT 302 N 4,200 m³/h 1,800 Pa 4 × Ø 100 3.0 kW €902.84
Bernardo DC 550 CF 4,400 m³/h 1,800 Pa 1×150 / 3×100 2.2 kW · 400 V €1,305.45
Bernardo DC 600 4,560 m³/h 2,340 Pa 3 bags n/a €1,268.85
Bernardo DC 700 6,800 m³/h 2,340 Pa 1×180 / 4×100 3.7 kW · 400 V €1,732.46
Bernardo DC 750 CF 7,800 m³/h 2,340 Pa 1×180 / 4×100 3.7 kW · 400 V €2,696.30
Bernardo FT 504 SF 8,900 m³/h 1,900 Pa n/a n/a €3,562.52

The rule shown by the table: diameter increases with airflow. Ø 100 up to around 1,500 m³/h, Ø 130 at around 2,500, Ø 150 at 4,400 and Ø 180 above 6,800. Connecting a Ø 100 hose to a Ø 180 inlet restricts the system and wastes the power you paid for.

One machine: from €234 to €590

For those running one machine at a time, the Bernardo DC 160 and DC 180, at €234.25 and €241.57, deliver 850 m³/h with 0.55 kW at 230 V. Bags of 40 and 56 litres, 80 dB, 18 kg: they can be moved by hand.

The DC 250 CF, at €590.50, increases airflow to 1,500 m³/h and, above all, changes the filter: a 2.25 m² cartridge instead of a fabric bag. It is the choice for sanding or working with MDF, where fine dust matters more than chips.

For site work, there is the portable BDC 1200 at €201.31: just 183 m³/h, but 2,500 Pa of suction pressure—the opposite of the workshop approach. It is designed for close-range pickup rather than moving large volumes of air.

Two machines: the DC 300 at €480.69

The Bernardo DC 300 offers the best balance in the range. It delivers 2,520 m³/h with a Y-adapter, one Ø 130 inlet or two Ø 100 inlets, and costs less than the DC 250 CF, which serves just one machine.

The reason is the filter: a 1.45 m² bag instead of a cartridge. It is perfectly suitable for solid wood and coarse chips. If you produce fine dust, the DC 450 CF, at €849.14, delivers 2,800 m³/h with a 4 m² cartridge and a 300-litre bag.

One point to note: two inlets do not mean two machines running simultaneously. It means two machines connected and used one at a time, with the blast gate closed on the other. To actually run both together, you need their combined airflow.

Three or four machines: FT 302 N and DC 550 CF

The FT 302 N, at €902.84, has four Ø 100 mm inlets and delivers 4,200 m³/h with 3.0 kW. This is the setup for a workshop with a saw, planer, spindle moulder and mitre saw permanently connected.

The DC 550 CF, at €1,305.45, delivers 4,400 m³/h with one Ø 150 inlet or three Ø 100 inlets, an 8 m² cartridge filter and two 300-litre bags. Its 2.2 kW motor uses a 400 V three-phase supply.

Further up the range, the DC 700, at €1,732.46, covers the department with 6,800 m³/h, a Ø 180 inlet, 3.7 kW three-phase power and four 190-litre bags.

When you need a cyclone system

A cyclone system separates coarse chips before they reach the filter, so it clogs much more slowly. It is for continuous operation, not for someone who switches on a machine twice a week.

The Bernardo RLA 1900, at €1,659.26, delivers 1,350 m³/h with 2,600 Pa and a self-cleaning cartridge filter, with a stated residual dust level of 0.1 mg/m³. Airflow is low for the price, but suction pressure is twice that of a conventional bag system, and the filter does not need manual cleaning.

If you already have a good extractor, you can add just the separator: the FSG 1000, at €561.22, connects upstream of systems rated at least 1.5 HP and extends the life of the main filter.

The deciding factor: health

Hardwood dust is classified as carcinogenic, and the occupational exposure limit is 2 mg/m³ over eight hours. In Italy, those working with beech, oak, chestnut or MDF fall under Title IX of Legislative Decree 81/2008, requiring extraction at source and documented measures.

The practical difference lies in the filter. A fabric bag traps chips but lets through the fine fraction—the part you breathe in. A cartridge of 2.25 m² or more, as fitted to the CF series, also captures that fraction.

For spaces where dust remains airborne, ceiling-mounted air filters are available: the Bernardo AC 1100, at €592.94, covers up to 55 m² with a 1-micron internal filter and a programmable timer. It complements extraction at source rather than replacing it.

How to choose in three steps

Count the machines you will use simultaneously. Not all the machines you own: only those running at the same time. This number determines the inlets needed.

Consider the material. A bag works for solid wood and coarse chips. MDF, plywood and sanding call for a cartridge.

Check the power supply. Single-phase 230 V versions are available up to 2,800 m³/h. Above 4,400, only 400 V three-phase versions are available, because at 2.2 kW the single-phase motor will not start.

The mistake I see most often: buying an extractor based on cubic metres, then connecting it with the wrong hose diameter. A Ø 150 inlet restricted to a Ø 100 hose loses more than half its airflow. The hose and fittings cost little compared with the machine, but determine whether it works.

Sandra Gaspar, founder of Krollit

Frequently asked questions

Which extractor do you need for a wood lathe?

A lathe produces chips concentrated at one point, so suction pressure matters more than airflow. A Bernardo RV 203 CF with 850 m³/h and 1,020 Pa at €359.91 is well suited to a single lathe. For site work, the portable BDC 1200 delivers 2,500 Pa with 183 m³/h at €201.31.

Which extractor do you need for a mitre saw?

A mitre saw cuts intermittently and produces coarse chips, so it does not require high airflow. One Ø 100 mm inlet with 850 m³/h is sufficient: the Bernardo DC 180 at €241.57 or the DC 160 at €234.25. A collection hood behind the blade is needed to capture the stream of chips.

How many machines can I connect to one extractor?

It depends on the inlets, not the airflow. The DC 300 has two Ø 100 inlets, the FT 302 N has four, and the DC 700 has four plus one Ø 180 inlet. However, two inlets mean two machines connected and used one at a time: running both simultaneously requires their combined airflow.

What airflow does a planer thicknesser need?

It is the most demanding machine in a woodworking shop. A PT 305 D removes up to 160 mm of thickness across a width of 305 mm and generates the highest volume of chips in the workshop. Below 1,500 m³/h, material remains between the rollers: the practical starting point is the DC 250 CF or above.

Which is better: a fabric bag or a cartridge filter?

The bag traps chips but lets fine dust through—the dust you breathe in. The cartridge, from 2.25 m² on the DC 250 CF to 16 m² on the DC 750 CF, also captures the fine fraction. For MDF, plywood and sanding, a cartridge is not optional.

When do you need a cyclone extractor?

When working continuously. The cyclone separates coarse chips before the filter, which clogs much more slowly and maintains constant airflow. The Bernardo RLA 1900 at €1,659.26 delivers 1,350 m³/h with 2,600 Pa and a self-cleaning filter. It does not pay off for occasional use.

Can an extractor run on a domestic power supply?

Single-phase 230 V versions are available up to 2,800 m³/h, such as the 1.5 kW DC 450 CF. Above that, from the DC 550 CF upwards, a 400 V three-phase supply is required because motors rated 2.2 kW and above will not start on a domestic supply.

What hose diameter should I use?

The diameter of the extractor inlet, without reductions. Ø 100 on models up to 1,500 m³/h, Ø 130 at around 2,500, Ø 150 at 4,400 and Ø 180 above 6,800. Restricting a Ø 150 inlet to a Ø 100 hose loses more than half the available airflow.

Is dust extraction mandatory in a woodworking shop?

Hardwood dust is classified as carcinogenic, and the occupational exposure limit is 2 mg/m³ over eight hours. In Italy, Title IX of Legislative Decree 81/2008 requires extraction at source and documented measures for employers whose staff work with beech, oak, chestnut or MDF.
