Bernardo DH 410 Thickness Planer – 400V
Bernardo DH 410 Thickness Planer – 400V is backordered and will ship as soon as it is back in stock.
Subscribe to our newsletter
Ricevi gli ultimi aggiornamenti su tutte le nostre nuove collezioni, saldi, offerte e date di arrivo dei prodotti.
-
Description
-
Sicurezza del prodotto
-
Reviews
Description
The Bernardo DH 410 – 400V thicknesser offers a working width of 410 mm, working height of 5–230 mm, Ø 95 mm shaft with 4 HSS blades at 4,050 rpm, a maximum cutting depth of 5 mm, automatic feed of 6 m/min, and a 3.0 kW three-phase 400V motor. Weight 239 kg. This is a thicknesser-only machine, it does not have a jointer function. Manufactured in Austria, distributed in Italy by Krollit as the official Bernardo distributor since 2007.
- Function: thickness planing only
- Working width: 410 mm
- Working height (min–max): 5 – 230 mm
- Shaft: Ø 95 mm – 4 HSS blades – 4,050 rpm
- Max cutting depth: 5 mm
- Feed rate: 6 m/min
- Motor: 3.0 kW S1 / 4.2 kW S6 – 400V three-phase
- Weight: 239 kg
Who uses the DH 410 and for what
The Bernardo DH 410 – 400V is a dedicated 410 mm thicknesser with HSS blades: the standard cutting edge version of the DH 410 S (which has a TCT spiral cutterhead). With a 410 mm width and thicknessing height up to 230 mm, it handles professional-sized doors, panels, and beams. The table with extensions (930 mm total) and integrated rollers facilitates feeding long workpieces. For those who already have a separate jointer and are looking for a 410 mm thicknesser at a lower cost than the TCT version. In Krollit customer workshops, it is used by carpenters and cabinetmakers who work continuously on wide pieces and accept periodic maintenance of HSS blades.
DH 410 (HSS) vs DH 410 S (TCT): which to choose
Same structure, same motor, same dimensions and weight (239 kg). The DH 410 uses 4 HSS blades, requiring sharpening every 1-4 weeks in professional use. The DH 410 S uses 72 TCT inserts, requiring rotation every 6-10 weeks per insert. The DH 410 has a lower purchase cost; the DH 410 S has lower maintenance costs over time. The choice depends on the volume and intensity of use.
Krollit Logistics and Support
Bernardo shipping in 5-9 business days (7 days for Southern Italy). Original Bernardo spare parts available from stock with 3-5 business day shipping. Customer support available in Italian.
Who is the Bernardo DH 410 – 400V for
| Profile | Compatibility | Reason |
|---|---|---|
| Passionate hobbyist | Not recommended | Professional dedicated thicknesser (239 kg, three-phase). For hobby use, consider combined jointer-planer machines. |
| Carpentry workshop with separate jointer | Recommended | 410 mm with 230 mm height, table with rollers: optimal for continuous thicknessing of wide workpieces. Lower purchase cost than the DH 410 S, with periodic HSS maintenance. |
| Continuous / industrial production | Suitable | For very high volumes, consider the DH 410 S with TCT to reduce maintenance downtime. The DH 410 HSS is suitable for shifts up to 6-7 hours on medium woods. |
Not recommended for: workshops without a separate jointer; workshops without 400V three-phase power; workpieces over 410 mm wide; those who also need a jointer function.
Thicknesser
| Specification | Value |
|---|---|
| Working width | 410 mm |
| Working height (min–max) | 5 – 230 mm |
| Table with extensions and rollers | 930 × 410 mm |
| Max cutting depth | 5 mm |
| Minimum workpiece length | 150 mm |
| Shaft – diameter | Ø 95 mm |
| Blades | 4 pcs HSS |
| Shaft speed | 4,050 rpm |
| Automatic feed | 6 m/min |
| Dust port connection | Ø 100 mm |
Motor and power supply
| Specification | Value |
|---|---|
| Motor power S1 (100%) | 3.0 kW (4.0 HP) |
| Motor power S6 (40%) | 4.2 kW (5.7 HP) |
| Power supply | 400V – three-phase |
Dimensions and weight
| Specification | Value |
|---|---|
| Machine dimensions (L × W × H) | 1,110 × 710 × 1,020 mm |
| Net weight | 239 kg |
Compliance and safety
| Specification | Value |
|---|---|
| Marking | CE |
| Directive | Machinery 2006/42/CE |
Standard equipment
- 4 mounted HSS blades
- Blade setting jig
Frequently asked questions
Does the DH 410 have a jointer function?
No. The DH 410 is exclusively a thicknesser. For a combined jointer-planer function at 410 mm, the AD 410, AD 410 S, or PT 410 S machines are the appropriate alternatives.
What is the difference between DH 410 and DH 410 S?
The DH 410 uses 4 HSS blades; the DH 410 S uses 72 TCT inserts. Structure, motor, dimensions, and weight are identical (239 kg). TCT offers approx. 50% reduced noise and 10-20 times longer cutting edge life. The DH 410 has a lower purchase cost; the DH 410 S has lower maintenance over time.
How often do the 4 HSS blades need sharpening?
In professional use (6-8 hours/day) on medium woods, sharpening is needed every 2-3 weeks. On hardwoods, every 1-2 weeks. Original Bernardo spare blades are available from Krollit stock with 3-5 business day shipping.
How much space is needed in the workshop?
The machine footprint is 1,110 × 710 × 1,020 mm. For feeding workpieces up to 410 mm wide, at least 2.5 m of clear space is needed in front and behind. With 239 kg Bernardo shipping.
What dust collector is needed for the DH 410?
The dust port connection is Ø 100 mm. For a 410 mm width, a dust collector with a minimum airflow of 800-1,000 m³/h is recommended. The Bernardo DC 600 (400V) is the recommended solution.
