BRHP 100 fixed cylinder hydraulic industrial press

The BRHP QZ series has a mobile cylinder head on four columns (Quick Zone): the cylinder moves horizontally to position itself over any point on the table without moving the workpiece. With the BRHP 100t, it is suitable for pressing off-centre workpieces, asymmetrical operations and operations where the workpiece cannot be centred under the fixed cylinder.

The nominal force of the BRHP 100t is the maximum force developed at the maximum pressure of the hydraulic system. At the beginning of the stroke (piston at the top dead centre) the force is the same – it is constant throughout the entire useful stroke. The included pressure gauge shows the pressure in bar: multiplying by the piston area gives the effective force in kN or tons.

Yes – all Bernardo BHP, HWP and BRHP presses include a pressure gauge for direct reading of the applied force. Indispensable for not exceeding the resistance of the pressed components (e.g. maximum interference of a bearing on the shaft) and for operations that require a specific assembly force.

Presses up to 100t are fixed to the floor with M12/M16 bolts on standard concrete (15–20 cm). For presses over 100t, check the floor's capacity with a structural engineer based on the base footprint. Customer support in Italian available.

Original spare parts available with 3–5 working day shipping. Customer support in Italian available.
